25.6 V and 51.2 V lithium iron phosphate batteries from 2.56 to 16.07 kWh, rated for 6000+ cycles and backed by a 5-year product warranty.
Four capacities.
2.56 kWh
SOC display · Bluetooth
5.1 kWh
LCD touch display
11.77 kWh
LCD touch display
16.07 kWh
LCD touch display
Storage built
to last.
LFP cell chemistry
Lithium iron phosphate cells in 8S1P (25.6 V) and 16S (51.2 V) configurations.
Long cycle life
Rated 6000+ cycles at 80% depth of discharge, 25 °C, 0.2C / 0.2C.
Scalable capacity
Every model supports up to 16 units in parallel.
Inverter-ready communication
RS485 and CAN for BMS communication, with WiFi and Bluetooth monitoring on 51.2 V models.
Wide operating window
Rated to 4000 m altitude, under 60% RH, with a defined storage window.
Installer-friendly
Wall-mount across the range, with an LCD touch display on every 51.2 V model.
Technical data.
| 25.6 V · 100 Ah | 51.2 V · 100 Ah | 51.2 V · 230 Ah | 51.2 V · 314 Ah | |
|---|---|---|---|---|
| Nominal energy | 2.56 kWh | 5.1 kWh | 11.77 kWh | 16.07 kWh |
| Cell chemistry | LFP | LFP | LFP | LFP |
| Standard charging current | 20 A | 20 A | 50 A | 50 A |
| Max continuous charge / discharge | 100 A | 100 A | 115 A | 150 A |
| Interfaces | Bluetooth | RS485 · CAN · WiFi · Bluetooth | RS485 · CAN · WiFi · Bluetooth | RS485 · CAN · WiFi · Bluetooth |
| Weight | 21.2 kg (gross) | 48 kg | 91.54 kg (net) | 135.96 kg (net) |
| Mounting | Wall | Wall | Wall | Wall |
| Cycle life | ≥ 6000 | ≥ 6000 | ≥ 6000 | ≥ 6000 |
| Product warranty | 5 years | 5 years | 5 years | 5 years |
Cycle life at 80% DOD, 25 °C, 0.2C / 0.2C. Full electrical and mechanical data are in the Prime datasheet (TZ-DS-PRIME-100-314).
Power when the
grid isn’t there.
Prime stores surplus solar during the day and supplies it in the evening or during a power cut.
Residential
Backup and self-consumption for homes.
Commercial
Scalable storage, up to 16 units in parallel.
Backup power
Keep essential loads running through outages.
